M0T61A Specification |
Mfg Part Number |
M0T61A |
Brand |
Hewlett Packard Enterprise |
Product series |
2040 Modular Smart Array (MSA 2040) |
Product category |
Storage |
Includes |
SFF Array Chassis
(2) MSA 2040 SAS controllers
4 x 200GB SFF SSDs
6 x 900GB 10K SFF HDDs
1 x Performance Auto Tier LTU |
Storage |
Bay Form Factor |
2.5" SFF |
Bay quantity |
24 |
Drives included |
4 x 200GB SFF SSDs
6 x 900GB 10K SFF HDDs |
Capacity |
Native: 6.2TB |
Max capacity in 1 chassis: 48 TB (single SFF array-head - using 24 x 2TB SFF SAS drives) |
Max capacitysupported: 398 TB (by adding 7 SFF Disk Enclosures behind SFF Array & using 2TB SFF SAS drives) |
Maximum Drives w/ expansion |
199 SFF |
Maximum LUNs |
512 |
Maximum LUN size |
140TB (128TiB) |
Storage Controller |
Cache Memory |
4GB Read/Write |
Cache Backup |
ECC protection with back up to flash memory (indefinite backup) |
Metadata and System OS memory |
2GB |
Upgradeable Firmware |
yes |
RAID Support |
RAID 0 , RAID 1 , RAID 10 , RAID 3 , RAID 5 , RAID 50 , RAID 6 |
Host Support |
Host supported |
SAS 6Gb/s or 12Gb/s |
Host Ports |
4 x 12 Gb mini-SAS HD using SAS 3.0 SFF-8644 connect interface (per controller) |
Expansion Port |
SAS (SFF8088) 4x lane 6 Gb SAS |
User Interface |
Status and activity provided via management interfaces.
Status Indicators on front of Controller |
Number of controller included |
Two SAS controllers |
Power requirement |
Power supply |
Internal power supply |
Input Power |
110VAC 3.32A, 344-390 W; 220VAC 1.61A,374-432W |
Max Input Power |
100-240 VAC, 50/60 Hz., 4.5-1.9A; 48-60 VDC 10.4A/8.3A |
Heat Dissipation |
1622 BTU/hr |
Temprature and humidity range |
Operating Temperature |
41°F to 104°F (5°C to 40°C) |
Operating Humidity |
10% to 90% RH @ 104°F (40°C) non-condensing |
Non-Operating Humidity |
Up to 93% RH @ 104°F (40°C) |
Declared acoustic noise levels |
Sound Power |
A weighted sound power LWAd=6,75 B |
Sound Pressure |
A weighted sound pressure LpAm - 55dB |
Regulatory Info |
Safety |
UL 60950-1 (USA)
CAN/CSA-C22.2 No.60950-1-03 (Canada)
EN 60950-1 (European Union)
GS mark (Germany)
IEC 60950-1 (International) |
Electromagnetic Compatibility |
UL 60950-1 (USA)
CAN/CSA-C22.2 No.60950-1-03 (Canada)
EN 60950-1 (European Union)
GS mark (Germany)
IEC 60950-1 (International)
CCC Mark (power supply only, China PRC)
Electromagnetic
Compatibility
VCCI:2008-04 Class A (Japan)
FCC 15:109(g) Class A (USA)
ICES-003:2004 Class A (Canada)
EN55022 : (European Union Class A); CISPR 22 (International Class A)
EN61000-3-2 : (Harmonics) (European Union)
EN61000-3-3 : (Flicker) (European Union)
EN 55024 (European Union, Immunity, Class A);CISPR 24 (International
Immunity, Class A)
AS/NZS CISPR 22, Class A (Australia, New Zealand)
CNS 13438 Taiwan, Class A (Taiwan)
KN22 Class A (Emissions Class A); KN24 (Immunity) (S Korea) |
RoHS and WEEE |
RoHS-6/6 Compliance, China RoHS, WEEE |
Weight and dimensions |
Form factor |
Rackmountable - 2U height |
Width |
7.6 in |
Depth |
19.5 in |
Height |
3.5 in |
Weight |
31 lbs |
