Q0U57B Specifications |
| Brand |
HPE |
| Product Name |
HPE StoreFabric SN6600B 32Gb 48/48 Power Pack+ Fibre Channel Switch |
| Model Number |
Q0U57B |
| Fibre Channel Ports |
48 active ports |
| Port Speed |
32 Gb/s Fibre Channel |
| Form Factor |
1U |
| Scalability |
Full fabric architecture of up to 239 switches |
| Media Type |
Hot-pluggable, LC connector; short wave (SWL), long wave (LWL), extended long wave (ELWL) |
| Fabric Services |
ISL Trunking, Advanced Performance Monitoring, Fabric Watch, Inter-Fabric Routing |
| Power Pack+ |
Included, providing advanced performance monitoring, security, and energy management features |
| Network Latency |
700 nanoseconds within switch |
| Management |
HTTP, SNMP v1/v3 (FE MIB, FC Management MIB), SSH; Auditing, Syslog; Advanced Web Tools, Advanced Zoning |
| Security Features |
DH-CHAP authentication between switches, Port Binding, IPSEC, Secure FTP |
| Operational Humidity Range |
10% to 85%, non-condensing |
| Storage Humidity Range |
10% to 93%, non-condensing |
| Operating Temperature Range |
0 to 40°C (32 to 104°F) |
| Storage Temperature Range |
-25 to 70°C (-13 to 158°F) |
| Warranty |
Limited warranty - parts and labour - 1 year - on-site - response time: next business day |
| Protocols Supported |
FC-PI-5, FC-PI-6, FC-FS-2, FC-LS-2, FC-GS-6, FC-IFR, FC-SW-6 |
| Compatibility |
Compatible with a wide range of HPE servers, storage, and SAN directors |
| Power Supply |
Dual, Hot-pluggable, redundant power supplies |
| Software Included |
HPE Power Pack+ Software Bundle |
