HPE StoreEasy 1860 Storage - Q2P77A

Model

HPE StoreEasy 1860 Storages

Processor

1 x Intel Xeon-Silver 4112 (2.6GHz/4-core/85W) or Intel Xeon-Bronze 3104 (1.7GHz/6-core/85W); 2ndprocessor optional

NOTE:The Xeon-Silver 4112 processor is only available on the HPE StoreEasy 1860 Performance Storage model (SKU# Q2P76A).

Memory

16GB (1 x HPE 16GB Dual Rank x8 DDR4-2666 CAS-19-19-19 Registered Smart Memory)

Storage Controller

HPE Smart Array P816i-a SR Gen10 (16 Internal Lanes/4GB Cache/SmartCache) 12G SAS Modular Controller for data drives

HPE Smart Array S100i SR Gen10 SW RAID for OS drives only

Internal Drive Support

24 SFF (2.5") hot-plug drive bays in front, optional 4SFF hot-plug rear-chassis drive cage

Network Port(s)

4 x 1GbE; optional FlexLOM adapter or PCIe NICs

Expansion Slots

3x PCIe; optional 3 slot secondary riser

Dimension

8.73 x 44.54 x 67.94 cm

3.44 x 17.54 x 26.75 in

Step 1: Choose an HPE StoreEasy 1860 model

BTO models

HPE StoreEasy 1860 Pre-configured Build-to-Order (BTO) models come with factory-installed data drives and the Microsoft Windows Storage Server 2016 Standard Edition operating system pre-installed on 2 x SFF Solid State Disk (SSD) drives on a M.2 card in rear PCIe slot.

HPE StoreEasy 1860 9.6TB SAS Storage

Q2P78A

NOTE:(8 x 1.2TB SAS 12G Enterprise 10K SFF Digitally Signed Firmware HDD pre-installed in front slots, 16 open SFF slots).

HPE StoreEasy 1860 14.4TB SAS Storage

Q2P79A

NOTE:(8 x 1.8TB SAS 12G Enterprise 10K SFF 512e Digitally Signed Firmware HDD pre-installed in front slots, 16 open SFF slots).

NOTE:Model names are based on raw storage capacity, not available user storage.

NOTE:When adding drives to the any of the 16 open SFF slots for the models above, Hewlett Packard Enterprise recommends as a best practice to use all internal data drives of the same type and capacity.

NOTE:All options in steps 2 to 9 of Configure-to-Order models are available for pre-configured BTO models. Ordered options ship separately and are not factory integrated.

CTO models

The HPE StoreEasy 1860 models Configure-to-Order (CTO) models come with factory-installed data drives and the Microsoft Windows Storage Server 2016 Standard Edition operating system pre-installed on 2 x SFF Solid State Disk (SSD) drives on a M.2 card in rear PCIe slot. The HPE StoreEasy 1860 CTO models can ship with just the OS drives and no factory installed data drives. If data drives are needed, select drives/drive bundles below for factory integration.

HPE StoreEasy 1860 Performance Storage

Q2P76A

HPE StoreEasy 1860 Storage

Q2P77A

NOTE:Hewlett Packard Enterprise recommends as a best practice that the internal data drives for the CTO models be the same type and capacity.

Step 2: Choose required internal storage drives

Drive Options

Minimum Number of internal drives required

0

Maximum Number of internal drives allowed

28 (with optional rear-chassis drive cage)

HPE StoreEasy 1860 LFF Drive Bundles

HPE 4.8TB SAS SFF Smart Carrier 4-pack HDD Bundle

Q2P84A

NOTE:Bundle contains 4 x HPE 1.2TB SAS 12G Enterprise 10K SFF (2.5in) SC 3yr Wty Digitally Signed Firmware HDD (SKU#872479-B21).

HPE 7.2TB SAS SFF Smart Carrier 4-pack HDD Bundle

Q2P85A

NOTE:Bundle contains 4 x HPE 1.8TB 12G SAS 7.2K rpm LFF (3.5-inch) SC 512e Helium 1yr WtyDigitally Signed Firmware Hard Drive(SKU#872481-B21).

HPE SSD Drive options (The following options are applicable for internal storage drives)

SmartCache Kit

HPE 1.6TB SFF Smart Carrier Smart Cache Kit

Q2P87A

NOTE:The Smart Cache kit contains 2 x HPE 800GB SAS 12G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD (SKU# 872376-B21) for use with the SmartCache feature included with the HPE Smart Array P816i-a SR Gen10 Storage Controller which provides a Flash Acceleration data tier to the HPE StoreEasy 1860.

SSDs

HPE 800GB SAS Write Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P04543-B21

HPE 800GB SAS Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P09090-B21

HPE 960GB SAS Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P06584-B21

HPE 1.6TB SAS Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P09092-B21

HPE 1.92TB SAS Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P06586-B21

HPE 3.2TB SAS Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P09094-B21

HPE 3.84TB SAS Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P06588-B21

HPE 6.4 TB SAS Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P09096-B21

NOTE:The recommended number of SSDs for the HPE StoreEasy 1860 is 8. HPE recommends the use of SAS SSDs as the HPE StoreEasy 1860 includes a SAS expander.

HDDs

HPE 1.2TB SAS 12G SFF (2.5in) SC 3yr Wty 512e Digitally Signed Firmware HDD

872479-B21

HPE 1.8TB SAS 12G SFF (2.5in) SC 3yr Wty 512e Digitally Signed Firmware HDD

872481-B21

HPE 2.4TB SAS 12G SFF (2.5in) SC 3yr Wty 512e Digitally Signed Firmware HDD

881457-B21

NOTE:Other SFF SC HDDs are compatible with HPE StoreEasy 1860. This is not intended to be an exhaustive list.

Step 3: Choose optional mid-chassis 4LFF drive cage

HPE StoreEasy 1860 4SFF Rear Drive Cage

Q2P94A

NOTE:Expands the number of Small Form Factor (2.5) drive slots from 24 to 28

NOTE:If the HPE StoreEasy 1860 Rear HDD Cage is selected, the optional Riser Kit (SKU# 870548-B21) cannot be selected and the maximum number of PCIe slots is 2.

Step 4: Choose optionalexternal storage controller to connect to external storage enclosures

HPE Smart Array SAS Controllers

HPE Smart Array E208e-p SR Gen10 (8 External Lanes/No Cache) 12G SAS PCIe Plug-in Controller

804398-B21

HPE Smart Array P408e-p SR Gen10 (8 External Lanes/4GB Cache) 12G SAS PCIe Plug-in Controller

804405-B21

HPE Smart Array SR Secure Encryption (Data at Rest Encryption/per Server Entitlement) E-LTU

Q2F26AAE

D3X10 or D6020 Disk Enclosures

The HPE StoreEasy 1860 models support the D3X10 or D6020 Disk Enclosure product families. A Smart Array controller with external ports must be added to the HPE StoreEasy 1860 to add external Disk Enclosures.

Step 5: Choose optional second Network Adapter

PCIe Network Adapters

HPE StoreEasy 1GbE 2-port 332T Adapter

Q2P90A

HPE StoreEasy 10GbE 2-port 530T Adapter

Q2P91A

HPE StoreEasy 10GbE 2-port 530SFP+ Adapter

Q2P92A

FlexLOM Network Adapters

HPE Ethernet 1Gb 4-port 366FLR Adapter

665240-B21

HPE Ethernet 10Gb 2-port 562FLR-SFP+ Adapter

727054-B21

HPE Ethernet 10Gb 2-port 535FLR-T Adapter

817721-B21

NOTE:FlexibleLOM Adapters provide flexibility in meeting networking needs now and adapt to any future requirements without using a standard PCIe slot. These options are field upgradeable, integrate seamlessly with the HPE StoreEasy system architecture and form factor. Only one FlexibleLOM can be added to the HPE StoreEasy 1860.

Step 6: Choose optional Riser Kit

HPE DL Gen10 x8/x16/x8 Riser Kit

870548-B21

NOTE:The Riser Kit also requires the HPE StoreEasy 1860 Xeon-Silver 4112 or Xeon-Bronze 3104 Performance Kit to be installed. The Riser Kit expands the number of available PCIe slots to 4.

NOTE:If the Riser Kit is selected, the optional HPE StoreEasy 1860 Rear HDD cage (SKU# Q2P94A) cannot be selected.

Step 7: Choose optional Performance Kit

HPE StoreEasy 1X60 Intel Xeon 4112 Performance Kit

Q2P88A

NOTE:The above Performance Kit can only be ordered with the HPE StoreEasy 1860 Performance model (SKU# Q2P76A). The kit contains one Xeon-Silver 4122 processor and one 16GB Dual Rank x8 DDR4-2666 CAS-19-19-19 RDIMM.

HPE StoreEasy 1X60 Intel Xeon 3104 Performance Kit

Q2P89A

NOTE:The above Performance Kit can be ordered with all HPE StoreEasy 1860 models except the HPE StoreEasy 1860 Performance model. The kit contains one Xeon-Bronze 3104 processor and one 16GB Dual Rank x8 DDR4-2666 CAS-19-19-19 RDIMM.

Step 8: Choose optional extra memory kit

HPE 16GB (1x16GB) Dual Rank x8 DDR4-2666 CAS-19-19-19 Registered Smart Memory Kit

835955-B21

NOTE:There are 12 DIMM slots per processor for a total maximum of 24 DIMM slots. All HPE StoreEasy 1860 models come with one processor and one 16GB DIMM standard.

Step 9: Choose optional System Recovery option

HPE StoreEasy XX60 Recovery Software Media Kit

Q2P95A

HPE StoreEasy 1860 Storages Specification

Processor

1 x Intel® Xeon-Silver 4112 (2.6GHz/4-core/85W) or Intel® Xeon-Bronze 3104 (1.7GHz/6-core/85W); 2ndprocessor optional

NOTE: The Xeon-Silver 4112 processor is only available on the HPE StoreEasy 1860 Performance Storage model (SKU# Q2P76A).

Memory

16GB (1 x HPE 16GB Dual Rank x8 DDR4-2666 CAS-19-19-19 Registered Smart Memory)

Storage Controller

HPE Smart Array P816i-a SR Gen10 (16 Internal Lanes/4GB Cache/SmartCache) 12G SAS Modular Controller for data drives

HPE Smart Array S100i SR Gen10 SW RAID for OS drives only

Internal Drive Support

24 SFF (2.5") hot-plug drive bays in front, optional 4SFF hot-plug rear-chassis drive cage

Network Port(s)

4 x 1GbE; optional FlexLOM adapter or PCIe NICs

Expansion Slots

3x PCIe; optional 3 slot secondary riser

NOTE: One PCIe slot occupied by M.2 SSD card and one PCIe slot occupied by SAS Expander.

Security

Trusted Platform Module 2.0 and 2U Lockable Security Bezel

Power

2 x 800W Platinum

Cooling

6 hot-plug, high-performance redundant fans

Form Factor

2U rack

Operating Systems

Microsoft® Windows Storage Server 2016, Standard Edition

Licenses

HPE iLO Advanced Premium Security Edition License with 1yr Support on Licensed Features

Dimension

8.73 x 44.54 x 67.94 cm

3.44 x 17.54 x 26.75 in
