HPE StoreEasy 1660 32TB SAS Storage - Q2P74A

Model

HPE StoreEasy 1660 Storage

Processor

Performance Model only: Intel Xeon-Silver 4112(2.6GHz/4-core/85W)Processor

All others models: Intel Xeon-Bronze 3104(1.7GHz/6-core/85W)Processor

Memory

Type

DDR4-2666 CAS-19-19-19 Registered (RDIMM)

Maximum

24TB (Limit based on operating system license - WSS2016)

Standard

16GB (1 x 16GB)

DIMM Sockets

24

Network Controller

NIC ports

4

Controller

1Gb Ethernet 4-port

Dimensions

LFF Drives:

8.73 x 44.54 x 73.02 cm

3.44 x 17.54 x 28.75 in

Step 1: Choose an HPE StoreEasy 1660 model

BTO models

HPE StoreEasy 1660 Pre-configured Build-to-Order (BTO) models come with factory-installed data drives and the Microsoft Windows Storage Server 2016 Standard Edition operating system pre-installed on 2 x SFF Solid State Disk (SSD) drives on a M.2 card in rear PCIe slot.

HPE StoreEasy 1660 16TB SAS Storage

Q2P73A

NOTE:(8 x 2TB SAS 12G Midline 7.2K LFF Digitally Signed Firmware HDDs pre-installed in front slots, 4 open LFF slots).

HPE StoreEasy 1660 32TB SAS Storage

Q2P74A

NOTE:(8 x 4TB SAS 12G Midline 7.2K LFF 512e Digitally Signed Firmware HDDs pre-installed in front slots, 4 open LFF slots).

HPE StoreEasy 1660 64TB SAS Storage

Q2P75A

NOTE:(8 x 8TB SAS 12G Midline 7.2K rpm LFF 512e Helium Digitally Signed Firmware HDDs pre-installed in front slots, 4 open LFF slots).

NOTE:Model names are based on raw storage capacity, not available user storage.

NOTE:When adding drives to the any of the 4 open LFF slots for the models above, Hewlett Packard Enterprise recommends as a best practice to use all internal data drives of the same type and capacity.

NOTE:All options in steps 2 to 9 of Configure-to-Order models are available for pre-configured BTO models. Ordered options ship separately and are not factory integrated.

CTO models

The HPE StoreEasy 1660 models Configure-to-Order (CTO) models come with factory-installed data drives and the Microsoft Windows Storage Server 2016 Standard Edition operating system pre-installed on 2 x SFF Solid State Disk (SSD) drives on a M.2 card in rear PCIe slot. The HPE StoreEasy 1660 CTO models can ship with just the OS drives and no factory installed data drives. If data drives are needed, select drives/drive bundles below for factory integration.

HPE StoreEasy 1660 Performance Storage

Q2P71A

HPE StoreEasy 1660 Storage

Q2P72A

NOTE:Hewlett Packard Enterprise recommends as a best practice that all internal data drives for the CTO models be the same type and capacity.

Step 2: Choose required internal storage drives

Drive Options

Minimum Number of internal drives required

0

Maximum Number of internal drives allowed

16 (with optional mid-chassis drive cage)

HPE StoreEasy 1660 LFF Drive Bundles

HPE 40TB SAS LFF Smart Carrier 4-pack HDD Bundle

Q0F60A

NOTE:Bundle contains 4 x HPE 10TB 12G SAS 7.2K rpm LFF (3.5-inch) SC 512e Helium 1yr Wty Digitally Signed Firmware HDD (SKU# 857644-B21).

HPE 32TB SAS LFF Smart Carrier 4-pack HDD Bundle

N9Y12A

NOTE:Bundle contains 4 x HPE 8TB 12G SAS 7.2K rpm LFF (3.5-inch) SC 512e Helium 1yr WtyDigitally Signed Firmware HDD (SKU# 861590-B21).

HPE 24TB SAS LFF Smart Carrier 4-pack HDD Bundle

Q2P82A

NOTE:Bundle contains 4 x HPE 6TB SAS 12G Midline 7.2K LFF (3.5in) SC 1yr Wty 512e Digitally Signed Firmware HDD (SKU# 861754-B21).

HPE 16TB SAS LFF Smart Carrier 4-pack HDD Bundle

Q2P81A

NOTE:Bundle contains 4 x HPE 4TB SAS 12G Midline 7.2K LFF (3.5in) SC 1yr Wty 512e Digitally Signed Firmware HDD (SKU# 861756-B21).

HPE 8TB SAS LFF Smart Carrier 4-pack HDD Bundle

Q2P80A

NOTE:Bundle contains 4 x HPE 2TB SAS 12G Midline 7.2K LFF (3.5in) SC 1yr Wty Digitally Signed Firmware HDD (SKU# 872485-B21).

HPE Drive options (The following options are applicable for internal storage drives)

SmartCache Kit

HPE 1.6TB LFF Smart Carrier Converter Smart Cache Kit

Q2P86A

SSDs

HPE 960GB SATA Read Intensive LFF SCC DS SSD

P09689-B21

HPE 1.92TB SATA Read Intensive LFF SCC DS SSD

P09693-B21

HPE 1.92TB SATA Mixed Use LFF SCC DS SSD

P09724-B21

HPE 960GB SATA Mixed Use LFF SCC DS SSD

P09718-B21

HPE 480GB SATA Mixed Use LFF SCC DS SSD

P07924-B21

HPE 800GB SAS Mixed Use LFF SCC DS SSD

P04529-B21

HDDs

HPE 2TB SAS 12G Midline 7.2K LFF (3.5in) SC 1yr Wty Digitally Signed Firmware HDD

872485-B21

HPE 4TB SAS 12G Midline 7.2K LFF (3.5in) SC 1yr Wty Digitally Signed Firmware HDD

872487-B21

HPE 6TB SAS 12G Midline 7.2K LFF (3.5in) SC 1yr Wty 512e HDD

861754-B21

HPE 8TB SAS 12G Midline 7.2K LFF (3.5in) SC 1yr Wty 512e Digitally Signed Firmware HDD

819201-B21

HPE 10TB SAS 12G Midline 7.2K LFF (3.5in) SC 1yr Wty Helium 512e Digitally Signed Firmware HDD

857644-B21

HPE 12TB SAS 12G Midline 7.2K LFF (3.5in) SC 1yr Wty Helium 512e Digitally Signed Firmware HDD

881779-B21

HPE 1TB SATA 6G Midline 7.2K LFF (3.5in) SC 1yr Wty HDD

861691-B21

HPE 2TB SATA 6G Midline 7.2K LFF (3.5in) SC 1yr Wty Digitally Signed Firmware HDD

872489-B21

HPE 4TB SATA 6G Midline 7.2K LFF (3.5in) SC 1yr Wty Digitally Signed Firmware HDD

872491-B21

HPE 6TB SATA 6G Midline 7.2K LFF (3.5in) SC 1yr Wty 512e HDD

861750-B21

HPE 8TB SATA 6G Midline 7.2K LFF (3.5in) SC 1yr Wty 512e Digitally Signed Firmware HDD

819203-B21

HPE 10TB SATA 6G Midline 7.2K LFF (3.5in) SC 1yr Wty Helium 512e Digitally Signed Firmware HDD

857648-B21

HPE 12TB SATA 6G Midline 7.2K LFF (3.5in) SC 1yr Wty Helium 512e Digitally Signed Firmware HDD

881785-B21

Step 3: Choose optional mid-chassis 4LFF drive cage

HPE StoreEasy 1660 4LFF Midplane Drive Cage

Q2P93A

NOTE:Expands the number of Large Form Factor (3.5) drive slots from 12 to 16.

Step 4: Choose optionalexternal storage controller to connect to external storage enclosures

HPE Smart Array SAS Controllers

HPE Smart Array E208e-p SR Gen10 (8 External Lanes/No Cache) 12G SAS PCIe Plug-in Controller

804398-B21

HPE Smart Array P408e-p SR Gen10 (8 External Lanes/4GB Cache) 12G SAS PCIe Plug-in Controller

804405-B21

HPE Smart Array SR Secure Encryption (Data at Rest Encryption/per Server Entitlement) E-LTU

Q2F26AAE

Step 5: Choose optional second Network Adapter

PCIe Network Adapter

HPE StoreEasy 1GbE 2-port 332T Adapter

Q2P90A

HPE StoreEasy 10GbE 2-port 530T Adapter

Q2P91A

HPE StoreEasy 10GbE 2-port 530SFP+ Adapter

Q2P92A

FlexLOM Network Adapters

HPE Ethernet 1Gb 4-port 366FLR Adapter

665240-B21

HPE Ethernet 10Gb 2-port 562FLR-SFP+ Adapter

727054-B21

HPE Ethernet 10Gb 2-port 535FLR-T Adapter

817721-B21

Step 6: Choose optional Riser Kit

HPE DL Gen10 x8/x16/x8 Riser Kit

870548-B21

NOTE:The Riser Kit also requires the HPE StoreEasy 1660 Xeon-Silver 4112 or Xeon-Bronze 3104 Performance Kit to be installed. The Riser Kit expands the number of available PCIe slots to 5.

Step 7: Choose optional Performance Kit

HPE StoreEasy 1X60 Intel Xeon 4112 Performance Kit

Q2P88A

NOTE:The above Performance Kit can only be ordered with the HPE StoreEasy 1660 Performance model (SKU# Q2P71A). The kit contains one Xeon-Silver 4122 processor and one 16GB Dual Rank x8 DDR4-2666 CAS-19-19-19 RDIMM.

HPE StoreEasy 1X60 Intel Xeon 3104 Performance Kit

Q2P89A

NOTE:The above Performance Kit can be ordered with all HPE StoreEasy 1660 models except the HPE StoreEasy 1660 Performance model. The kit contains one Xeon-Bronze 3104 processor and one 16GB Dual Rank x8 DDR4-2666 CAS-19-19-19 RDIMM.

Step 8: Choose optional extra memory kit

HPE 16GB (1x16GB) Dual Rank x8 DDR4-2666 CAS-19-19-19 Registered Smart Memory Kit

835955-B21

NOTE:There are 12 DIMM slots per processor for a total maximum of 24 DIMM slots. All HPE StoreEasy 1660 models come with one processor and one 16GB DIMM standard.

Step 9: Choose optional System Recovery option

HPE StoreEasy XX60 Recovery Software Media Kit

Q2P95A

HPE StoreEasy 1660 Storage Specification

Processor

1 x Intel® Xeon-Silver 4112 (2.6GHz/4-core/85W) or Intel® Xeon-Bronze 3104 (1.7GHz/6-core/85W); 2ndprocessor optional

NOTE: The Xeon-Silver 4112 processor is only available on the HPE StoreEasy 1660 Performance Storage model (SKU# Q2P71A).

Memory

16GB (1 x HPE 16GB Dual Rank x8 DDR4-2666 CAS-19-19-19 Registered Smart Memory)

Storage Controller

HPE Smart Array P816i-a SR Gen10 (16 Internal Lanes/4GB Cache/SmartCache) 12G SAS Modular Controller for data drives

HPE Smart Array S100i SR Gen10 SW RAID for OS drives only

Internal Drive Support

12 LFF (3.5") hot-plug drive bays in front, optional 4LFF hot-plug mid-chassis drive cage

Network Port(s)

4 x 1GbE; optional FlexLOM adapter or PCIe NICs

Expansion Slots

3x PCIe; optional 3 slot secondary riser

NOTE: One PCIe slot occupied by M.2 SSD card.

Security

Trusted Platform Module 2.0 and 2U Lockable Security Bezel

Power

2 x 800W Platinum

Cooling

6 hot-plug, high-performance redundant fans

Form Factor

2U rack

Operating Systems

Microsoft® Windows Storage Server 2016, Standard Edition

Licenses

HPE iLO Advanced Premium Security Edition License with 1yr Support on Licensed Features

Dimensions

LFF Drives:

8.73 x 44.54 x 73.02 cm

3.44 x 17.54 x 28.75 in

Input Requirements

(per power supply)

Rated Line Voltage: 100 to 120 VAC / 200 to 240 VAC

BTU Rating (Maximum)

For 800W Power Supply: 3207 BTU/hr (at 100 VAC), 3071 BTU/hr (at 200 VAC), 3112 BTU/hr (at 240 VAC) for China Only

For 500W Power Supply: 1979 BTU/hr (at 100 VAC), 1911 BTU/hr (at 200 VAC), 1965 BTU/hr (at 240 VAC) for China Only
