Step 1: Choose a Base Model |
BTO models |
The StoreEasy 1650 Expanded comes with two Solid State Disks on a M.2 Enablement Kit in PCIe slot factory-configured as RAID 1 with theWSS2016 OS pre-installed (depending on model selected). The StoreEasy 1650 Expanded can ship with just the OS drives and no data drives.If data drives are needed, select the drives for factory integration. |
StoreEasy 1650 Expanded WSS2016 Storage |
Q0F50A |
NOTE: This model does not include pre-configured data drives. Data drives can be added for factory integration. |
Step 2: Choose required internal storage and optional external storage drives |
Drive Options |
Minimum Number of internal drives required |
0 |
Maximum Number of internal drives allowed |
28 |
StoreEasy 1650 Expanded LFF Drive Bundles |
HPE StoreEasy 16TB SAS LFF (3.5in) Low profile 4-pack HDD Bundle |
N9Y43A |
NOTE: Bundle contains 4 x HPE 4TB 12G SAS 7.2K rpm LFF (3.5-inch) Low Profile Midline 1yr Warranty Hard Drive (SKU# 833928-B21). |
HPE StoreEasy 32TB SAS LFF (3.5in) Low profile 4-pack HDD Bundle |
N9Y45A |
NOTE: Bundle contains 4 x HPE 8TB 12G SAS 7.2K rpm LFF (3.5-inch) Low Profile Midline 1yr Warranty Hard Drive (SKU#834031-B21). |
HPE StoreEasy 32TB SATA LFF (3.5in) Low profile 4-pack HDD |
N9Y46A |
NOTE: Bundle contains 4 x HPE 8TB 6G SATA 7.2K rpm LFF (3.5-inch) Low Profile Midline 1yr Warranty Hard Drive (SKU#834028-B21). |
HPE StoreEasy 40TB SAS LFF (3.5in) Low profile 4-pack HDD |
Q0F61A |
NOTE: Bundle contains 4 x HPE 10TB 12G SAS 7.2K rpm LFF (3.5-inch) Low Profile Midline 1yr Warranty Hard Drive (SKU#857646-B21). |
HPE StoreEasy 40TB SATA LFF (3.5in) Low Profile 4-pack HDD Bundle |
Q0F62A |
NOTE: Bundle contains 4 x HPE 10TB 6G SATA 7.2K rpm LFF (3.5-inch) Low Profile Midline 1yr Warranty Hard Drive (SKU#857650-B21). |
HPE StoreEasy 48TB SATA LFF (3.5in) Low Profile Carrier 4-pack HDD Bundle |
Q2S06A |
NOTE: Bundle contains 4 x HPE 12TB 6G SATA 7.2K rpm LFF (3.5-inch) LP 1yr Wty Helium 512e Digitally Signed Firmware HDD (SKU# 881787-B21). |
|
D3000 or D6000 Disk Enclosures
The StoreEasy 1650 Expanded support all of the HPE D3000, D6000 and D6020 Disk Enclosures to add additional capacity. A Smart Array withexternal Ports must be added to the StoreEasy 1650 Expanded to add external Disk Enclosures.
|
Step 3: Choose optional external storage controller |
SAS Controllers HPE Smart Array Controllers |
HPE Smart Array P441/4GB FBWC 12Gb 2-ports Ext SAS Controller |
726825-B21 |
HPE Smart Host Bus Adapters |
HPE H241 12Gb 2-ports Ext Smart Host Bus Adapter |
726911-B21 |
Step 4: Choose optional second Network Adapter |
NOTE: HPE 361i 1GbEthernet 2-port Network Adapter is included in all of the StoreEasy 1650 Expanded models. Recommended option for additionalnetwork connectivity is HPE Ethernet 10Gb 2-port 560SFP+ Adapter C SKU#665249-B21. |
|
1 Gigabit Ethernet adapters
Broadcom chipset-based with RSS, VMQ, VMWNQ, VMDq, MSI-X, EEE features
|
HPE Ethernet 1Gb 4-port 331T Adapter |
647594-B21 |
HPE Ethernet 1Gb 2-port 332T Adapter |
615732-B21 |
10/25 Gigabit Ethernet adapters |
NOTE: A minimum of two Gigabytes (2 GB) of system memory is required per each adapter. |
Intel chipset-based with RSS, VMQ, VMWNQ, VMDq, MSI-X, EEE features |
HPE Ethernet 10Gb 2-port 560SFP+ Adapter |
665249-B21 |
HPE Ethernet 10Gb 2-port 561T Adapter |
716591-B21 |
HPE Ethernet 10Gb 2-port 562SFP+ Adapter |
727055-B21 |
QLogic chipset-based with RSS, VMQ, VMWNQ, VMDq, MSI-X features |
HPE Ethernet 10Gb 2-port 530SFP Adapter |
652503-B21 |
HPE Ethernet 10Gb 2-port 530T Adapter |
656596-B21 |
Mellanox chipset-based with RDMA, RSS, VMQ, VMWNQ, MSI-X, EEE features |
HPE Ethernet 10Gb 2-port 546SFP+ Adapter |
779793-B21 |
HPE Ethernet 10/25Gb 2-port 640SFP28 Adapter |
817753-B21 |
|
FlexibleLOM Adapters
NOTE: FlexibleLOM Adapters provide flexibility in meeting networking needs now and adapt to any future requirements without using a standardPCIe slot.These options are field upgradeable, integrate seamlessly with the StoreEasy system architecture and form factor. Only one FlexibleLOMcan be addedto the StoreEasy 1650 Expanded.
|
Emulex chipset-based with RDMA, RSS, VMQ, VMWNQ, MSI-X features |
HPE FlexFabric 10Gb 2-port 556FLR-SFP+ Adapter |
727060-B21 |
Intel chipset-based with RSS, VMQ, VMWNQ, VMDq, MSI-X, EEE features |
HPE Ethernet 10Gb 2-port 561FLR-T Adapter |
700699-B21 |
HPE Ethernet 10Gb 2-port 560FLR-SFP+ Adapter |
665243-B21 |
HPE Ethernet 1Gb 4-port 366FLR Adapter |
665240-B21 |
HPE Ethernet 10Gb 2-port 562FLR-SFP+ Adapter |
727054-B21 |
Mellanox chipset-based with RDMA, RSS, VMQ, VMWNQ, MSI-X features |
HPE Ethernet 10Gb 2-port 546FLR-SFP+ Adapter |
779799-B21 |
HPE Ethernet 10/25Gb 2-port 640FLR-SFP28 Adapter |
817749-B21 |
QLogic chipset-based with RSS, VMQ, VMWNQ, VMDq, MSI-X features |
HPE FlexFabric 10Gb 2-port 533FLR-T Adapter |
700759-B21 |
HPE FlexFabric 10Gb 2-port 534FLR-SFP+ Adapter |
700751-B21 |
HPE FlexFabric 10Gb 4-port 536FLR-T Adapter |
764302-B21 |
|
Infiniband Adapters
NOTE: Direct Attach Cable (DAC) for copper environments or fiber transceivers and cables for fiber-optic environments must be purchased separately.
|
HPE InfiniBand FDR/Ethernet 10Gb/40Gb 2-port 544+QSFP Adapter |
764284-B21 |
HPE InfiniBand FDR/Ethernet 10Gb/40Gb 2-port 544+FLR-QSFP Adapter |
764285-B21 |
HPE InfiniBand QDR/Ethernet 10Gb 2-port 544+FLR-QSFP Adapter |
764286-B21 |
HPE 100Gb 1-port OP101 QSFP28 x16 PCIe Gen3 with Intel Omni-Path Architecture Adapter |
829335-B21 |
Step 5: Choose optional second processor (StoreEasy 1650 Expanded WSS2016 Storage model only) |
HPE StoreEasy 1650 Expanded E5-2609v4 Processor Upgrade |
Q0F70A |
NOTE: Q0F70A is not factory integrated on Q0F50A by default. |
Step 6: Choose optional extra memory kit |
NOTE: Add the same type memory to the product that is shipped standard with the product |
Registered DIMMs (RDIMMs) for E5-2600v4 Series |
HPE 8GB (1x8GB) Single Rank x8 DDR4-2400 CAS-17-17-17 Registered Memory Kit |
805347-B21 |
HPE 16GB (1x16GB) Single Rank x4 DDR4-2400 CAS-17-17-17 Registered Memory Kit |
805349-B21 |
NOTE: The above memory kit needs to be ordered only with StoreEasy 1650 Expanded WSS2016 CTO model |
Registered DIMMs (RDIMMs) for E5-2600v3 Series |
HPE 8GB (1x8GB) Single Rank x4 DDR4-2133 CAS-15-15-15 Registered Memory Kit |
726718-B21 |
HPE 16GB (1x16GB) Dual Rank x4 DDR4-2133 CAS-15-15-15 Registered Memory Kit |
726719-B21 |
NOTE: The above memory kit needs to be ordered only with StoreEasy 1650 Expanded models. |
Step 7: Choose optional Security option |
HPE Trusted Platform Module 2.0 Kit |
745823-B21 |
HPE Trusted Platform Module Option |
488069-B21 |
Step 8: Choose optional System Recovery option |
HPE StoreEasy XX50 WSS2016 Recovery Software Kit |
Q0F58A |
