HPE StoreEasy 1560 8TB SATA Storage - Q2R96A

Model

HPE StoreEasy 1560 Storage

Processor

Intel Xeon-Bronze 3104

(1.7GHz/6-core/85W) Processor

Memory

Type

DDR4-2666 CAS-19-19-19 Registered (RDIMM)

Maximum

24TB (Limit based on operating system license - WSS2016)

Standard

8GB (1 x 8GB)

DIMM Sockets

6

Network Controller

NIC ports

2

Controller

1Gb Ethernet 4-port

Dimensions

17.32 (H)x 7.68 (W) x 18.92. (D) in (44 x 19.5 x 48.05 cm)

Step 1: Choose an HPE StoreEasy 1560 BTO model

HPE StoreEasy 1560 Pre-configured Build-to-Order (BTO) models come with four factory-installed data drives and the Microsoft Windows Storage Server 2016 Standard Edition operating system pre-installed on a 150GB RAID10 partition across the four drives.

HPE StoreEasy 1560 8TB SATA Storage

Q2R96A

NOTE:(4 x 2TB SATA 6G Midline 7.2K LFF Digitally Signed Firmware HDDs pre-installed).

HPE StoreEasy 1560 16TB SATA Storage

Q2R97A

NOTE:(4 x 4TB SATA 6G Midline 7.2K LFF 512e Digitally Signed Firmware HDDs pre-installed).

NOTE:Model names are based on raw storage capacity, not available user storage.

NOTE:All options in steps 2 to 8 of Build-to-Order models are shipped separately and are not factory integrated.

Step 2: Choose optionalexternal storage controller to connect to external storage enclosures

HPE Smart Array SAS Controllers

HPE Smart Array E208e-p SR Gen10 (8 External Lanes/No Cache) 12G SAS PCIe Plug-in Controller

804398-B21

HPE Smart Array P408e-p SR Gen10 (8 External Lanes/4GB Cache) 12G SAS PCIe Plug-in Controller

804405-B21

HPE Smart Array SR Secure Encryption (Data at Rest Encryption/per Server Entitlement) E-LTU

Q2F26AAE

Step 3: Choose optional second Network Adapter

PCIe Network Adapters

HPE StoreEasy 1GbE 2-port 332T Adapter

Q2P90A

HPE Ethernet 1Gb 4-port 331T Adapter

647594-B21

HPE StoreEasy 10GbE 2-port 530T Adapter

Q2P91A

HPE StoreEasy 10GbE 2-port 530SFP+ Adapter

Q2P92A

Step 4: Choose optional extra memory kit

HPE 16GB (1x16GB) Dual Rank x8 DDR4-2666 CAS-19-19-19 Registered Smart Memory Kit

835955-B21

NOTE:There are 6 DIMM slots available on the HPE StoreEasy 1560. All HPE StoreEasy 1560 models come with one processor and one 8GB DIMM standard.

Step 5: Choose optional 2ndLFF drive cage

HPE ML110 Gen10 4LFF Drive Backplane Cage Kit

869491-B21

NOTE:Adding the 2ndLFF drive cage requires adding the 2ndpower supply (sku865408-B21).

Step 6: Choose additional HDDs for 2ndLFF drive cage optional 2nd

HPE 1TB SATA 6G Midline 7.2K LFF (3.5in) LP 1yr Wty Digitally Signed Firmware HDD

861686-B21

HPE 2TB SATA 6G Midline 7.2K LFF (3.5in) LP 1yr Wty Digitally Signed Firmware HDD

861681-B21

HPE 4TB SATA 6G Midline 7.2K LFF (3.5in) LP 1yr Wty Digitally Signed Firmware HDD

861683-B21

HPE 6TB SATA 6G Midline 7.2K LFF (3.5in) LP 1yr Wty 512e HDD

861742-B21

HPE 8TB SATA 6G Midline 7.2K LFF (3.5in) LP 1yr Wty 512e Digitally Signed Firmware HDD

834028-B21

HPE 12TB SATA 6G Midline 7.2K LFF (3.5in) LP 1yr Wty Helium 512e Digitally Signed Firmware HDD

881787-B21

Step 7: Choose optional 2ndpower supply

HPE 500W Flex Slot Platinum Hot Plug Low Halogen Power Supply Kit

865408-B21

Step 8: Choose optional System Recovery option

HPE StoreEasy XX60 Recovery Software Media Kit

Q2P95A

HPE StoreEasy 1560 Storage Specification

Processor

1 x Intel® Xeon-Bronze 3104 (1.7GHz/6-core/85W) Processor

Memory

8GB (1 x HPE 8GB Single Rank x8 DDR4-2666 CAS-19-19-19 Registered Smart Memory)

Storage Controller

HPE Smart Array P408i-p SR Gen10 (8 Internal Lanes/2GB Cache) 12G SAS Modular Controller

Internal Drive Support

4 LFF (3.5") hot-plug drive bays standard; upgradable to 8 by adding second drive cage

Network Port(s)

2 x 1GbE; optional PCIe NICs

Expansion Slots

5x PCIe (one slot occupied by Smart Array P408i-p controller)

Security

Trusted Platform Module 2.0 and Lockable Security Bezel

Power

1 x 500W Platinum standard; optional 2nd redundant power supply

Cooling

2 non hot-plug redundant fans

Form Factor

4.5U tower

Operating Systems

Microsoft Windows Storage Server 2016, Standard Edition

Licenses

HPE iLO Advanced Premium Security Edition License with 1yr Support on Licensed Features

Dimensions

17.32 (H)x 7.68 (W) x 18.92. (D) in (44 x 19.5 x 48.05 cm)

Input Requirements

(per power supply)

Rated Line Voltage: 100 to 120 VAC

Rated Input Frequency: For 350W & 550W Power Supply:8A (at 100~240 VAC), 50 to 60 Hz

Rated Input Power:

For 550 W Power Supply:< 639 W (at 100 VAC), < 605 W (at 200 VAC)

For 350 W Power Supply:< 427 W (at 100 VAC), < 427 W (at 200 VAC)

BTU Rating (Maximum)

For 550 W Power Supply:2204 BTU/hr (at 100 VAC), 2113 BTU/hr (at 200 VAC)

For 350 W Power Supply:1452 BTU/hr (at 100 VAC), 1544 BTU/hr (at 200 VAC)

Power Supply Output

(per power supply)

Rated Steady-State Power:

For 550 W Power Supply:550 W (at 100 VAC),550 W (at 200 VAC)

Maximum Peak Power:

For 350 W Power Supply:350 W (at 100 VAC),350 W (at 200VAC)
