HPE StoreEasy 1460 32TB SATA Storage - Q2R94A

Model

HPE StoreEasy 1460 Storage

Processor

Intel® Xeon-Bronze 3104
(1.7GHz/6-core/85W) Processor

Memory

Type

DDR4-2666 CAS-19-19-19 Registered (RDIMM)

Maximum

24TB (Limit based on operating system license - WSS2016)

Standard

8GB (1 x 8GB)

DIMM Sockets

24

Network Controller

NIC ports

4

Controller

1Gb Ethernet 4-port

Dimensions

LFF Drives:

4.29 x 43.46 x 74.98 cm

1.69 x 17.11 x 29.5 in

Step 1: Choose an HPE StoreEasy 1460 BTO model

HPE StoreEasy 1460 Pre-configured Build-to-Order (BTO) models come with four factory-installed data drives and the Microsoft Windows Storage Server 2016 Standard Edition operating system pre-installed on a 150GB RAID10 partition across the four drives.

HPE StoreEasy 1460 8TB SATA Storage

Q2R92A

NOTE: (4 x 2TB SATA 6G Midline 7.2K LFF Digitally Signed Firmware HDDs pre-installed in front slots).

HPE StoreEasy 1460 16TB SATA Storage

Q2R93A

NOTE: (4 x 4TB SATA 6G Midline 7.2K LFF 512e Digitally Signed Firmware HDDs pre-installed in front slots).

HPE StoreEasy 1460 32TB SATA Storage

Q2R94A

NOTE: (4 x 8TB SATA 6G Midline 7.2K rpm LFF 512e Helium Digitally Signed Firmware HDDs pre-installed in front slots).

NOTE: Model names are based on raw storage capacity, not available user storage.

NOTE: All options in steps 2 to 8 of Build-to-Order models are shipped separately and are not factory integrated.

Step 2: Choose optional external storage controller to connect to external storage enclosures

HPE Smart Array SAS Controllers

HPE Smart Array E208e-p SR Gen10 (8 External Lanes/No Cache) 12G SAS PCIe Plug-in Controller

804398-B21

HPE Smart Array P408e-p SR Gen10 (8 External Lanes/4GB Cache) 12G SAS PCIe Plug-in Controller

804405-B21

HPE Smart Array SR Secure Encryption (Data at Rest Encryption/per Server Entitlement) E-LTU

Q2F26AAE

Step 3: Choose optional second Network Adapter

PCIe Network Adapters

HPE StoreEasy 1GbE 2-port 332T Adapter

Q2P90A

HPE Ethernet 1Gb 4-port 331T Adapter

647594-B21

HPE StoreEasy 10GbE 2-port 530T Adapter

Q2P91A

HPE StoreEasy 10GbE 2-port 530SFP+ Adapter

Q2P92A

FlexLOM Network Adapters

HPE Ethernet 1Gb 4-port 366FLR Adapter

665240-B21

HPE Ethernet 10Gb 2-port 562FLR-SFP+ Adapter

727054-B21

HPE Ethernet 10Gb 2-port 535FLR-T Adapter

817721-B21

NOTE: FlexibleLOM Adapters provide flexibility in meeting networking needs now and adapt to any future requirements without using a standard PCIe slot. These options are field upgradeable, integrate seamlessly with the HPE StoreEasy system architecture and form factor. Only one FlexibleLOM can be added to the HPE StoreEasy 1460.

Step 4: Choose optional Riser Kit to add PCIe slot 3

HPE DL360 Gen10 Low Profile Riser Kit

867982-B21

NOTE: The Riser Kit also requires the Intel® Xeon-Bronze 3104 Processor to be installed. The Riser Kit expands the number of available PCIe slots to 3.

Step 5: Choose optional 2nd processor

HPE DL360 Gen10 Intel Xeon-Bronze 3104 (1.7GHz/6-core/85W) Processor Kit

860649-B21

Step 6: Choose optional extra memory kit

HPE 16GB (1x16GB) Dual Rank x8 DDR4-2666 CAS-19-19-19 Registered Smart Memory Kit

835955-B21

NOTE: There are 12 DIMM slots per processor for a total maximum of 24 DIMM slots. All HPE StoreEasy 1460 models come with one processor and one 8GB DIMM standard.

NOTE: Dual processor HPE StoreEasy 1460 systems must have the same number and type of memory DIMMs installed on each processor.

Step 7: Choose optional 2nd power supply

HPE 500W Flex Slot Platinum Hot Plug Low Halogen Power Supply Kit

865408-B21

Step 8: Choose optional System Recovery Media

HPE StoreEasy XX60 Recovery Software Media Kit

Q2P95A

HPE StoreEasy 1460 Storage Specification

Processor

1 x Intel® Xeon-Bronze 3104 (1.7GHz/6-core/85W) Processor; 2nd processor optional

Memory

8GB (1 x HPE 8GB Single Rank x8 DDR4-2666 CAS-19-19-19 Registered Smart Memory)

Storage Controller

HPE Smart Array P408i-a SR Gen10 (8 Internal Lanes/2GB Cache) 12G SAS Modular Controller

Internal Drive Support

4 LFF (3.5") hot-plug drive bays in front

Network Port(s)

4 x 1GbE; optional FlexLOM adapter or PCIe NICs

Expansion Slots

2x PCIe; optional secondary riser with one additional PCIe slot

Security

Trusted Platform Module 2.0 and 1U Lockable Security Bezel

Power

1 x 500W Platinum standard; optional 2nd redundant power supply

Cooling

5 hot-plug redundant fans (single processor), 7 hot-plug redundant fans (dual processors)

Form Factor

1U rack

Operating Systems

Microsoft® Windows Storage Server 2016, Standard Edition

Licenses

HPE iLO Advanced Premium Security Edition License with 1yr Support on Licensed Features

Dimensions

LFF Drives:

4.29 x 43.46 x 74.98 cm

1.69 x 17.11 x 29.5 in

Input Requirements

(per power supply)

Rated Line Voltage:

100 to 120 VAC

200 to 240 VAC

BTU Rating

Maximum: For 500W Power Supply: 1979 BTU/hr (at 100 VAC), 1911 BTU/hr (at 200 VAC), 1965 BTU/hr (at 240 VDC) for China Only

Power Supply Output

(per power supply)

Rated Steady-State Power:

For 500W Power Supply: 500W (at 100 VAC), 500W (at 240 VAC), 500W (at 240 VDC) input for China
