HPE MSA 2052 Storage
Array
Access Type
Block
Form Factor
2U, SFF or LFF
Number of controllers per array
2
Number of host ports per array
8
FC host connectivity
8/16Gb
iSCSI host connectivity
1Gb or 10GbI
SAS host connectivity
6/12Gb
Cache, per array
Max Read cache per array
8TB
Data (read/write) cache + system memory per array
16GB
Pool Capacity (with Large Pool Support)
562 TB (512 TiB)
RAID Levels supported: Virtual mode
RAID 1, 5, 6, 10
Enclosures
Expansion Drive Enclosures
0-7 enclosures
LFF/SFF array/enclosure mixing
Supported
Maximum number of drives per array enclosure
24 SFF/12 LFF
Maximum number of drives per drive enclosure
24 SFF/12 LFF
Drive enclosure interface type
6Gb SAS
①
AC Power supplies
④
Management Ethernet port
②
Host connection ports
8 and/or 16Gb FC,
1 GBE and/or 10GbeE iSCS,
I or 6GB and/or 12Gb SAS
⑤
Expansion port
③
CLI port (mini-USB)
HPE MSA 2052 Storage Specification Array
Access Type
Block
Form Factor
2U, SFF or LFF
Number of controllers per array
2
Number of host ports per array
8
FC host connectivity
8/16Gb
iSCSI host connectivity
1Gb or 10GbI
SAS host connectivity
6/12Gb
Cache, per array
Max Read cache per array
8TB
Data (read/write) cache + system memory per array
16GB
Pool Capacity (with Large Pool Support)
562 TB (512 TiB)
RAID Levels supported: Virtual mode
RAID 1, 5, 6, 10
Enclosures
Expansion Drive Enclosures
0-7 enclosures
LFF/SFF array/enclosure mixing
Supported
Maximum number of drives per array enclosure
24 SFF/12 LFF
Maximum number of drives per drive enclosure
24 SFF/12 LFF
Drive enclosure interface type
6Gb SAS
Drives
Maximum total HDDs per array
192 SFF / 96 LFF
Maximum total SSDs per array
192 SFF / 96 LFF
Max raw capacity per array enclosure
76.8 TB SFF / 144TB LFF
Max raw capacity per drive enclosure
76.8 TB SFF / 144TB LFF
Max raw capacity per array
614.4TB SFF / 1152TB LFF
Integrated SSDs
2x800GB Mixed Use SSDs
Drive Capacities
SFF SSDs (Mixed Use)
400GB, 800GB, 1.6TB, 3.2TB
LFF SSDs (Mixed Use)
400GB, 800GB
SFF HDDs
15K: 300GB, 600GB, 900GB
10K: 300GB, 600GB, 1.2TB, 1.8TB, 2.4TB
LFF HDDs
7.2K: 2TB, 4TB, 6TB, 8TB, 10TB, 12TB
SEDs
Encryption not supported
Software Features
Thin Technologies
Thin Provisioning, Space Reclamation, Thin Rebuild
Tiering
Performance Tier, Standard Tier, Archive Tier
Replication
Snapshots (512), Volume Copy, Remote Snaps
Quality of Service
Virtual Tier Affinity
Bundled/Integrated Licenses
Advanced Data Services LTU standard
Additional Features
Maximum number of volumes
512
Maximum number of snapshots
512
Maximum number of hosts
512
Maximum number of initiators
1024
Customer self-installable
Yes
Customer self-repairable
Yes
Customer self-upgradeable
Yes
File Services
Yes
HPE Storage File Controller
HPE Q1J31A is the HPE MSA 2052 SAS Dual Controller SFF Storage. The MSA 2052 is a pre-configured bundle that includes an MSA 2050-branded LFF array chassis, two AC power supplies, two MSA 2050 SAS controllers, two 800GB Mixed Use SSDs, one Advanced Data Services LTU, two .7m PDU cords (IEC C14), and one rack-mount kit. The two 800GB SSDs are shipped integrated in the MSA 2050 array. The Advanced Data Services LTU is shipped with the MSA 2050 array and requires license activation.
Quick Spec Table 1 shows the quick spec of HPE MSA 2052 Storage.
HPE MSA 2052 Storage
Array
Access Type
Block
Form Factor
2U, SFF or LFF
Number of controllers per array
2
Number of host ports per array
8
FC host connectivity
8/16Gb
iSCSI host connectivity
1Gb or 10GbI
SAS host connectivity
6/12Gb
Cache, per array
Max Read cache per array
8TB
Data (read/write) cache + system memory per array
16GB
Pool Capacity (with Large Pool Support)
562 TB (512 TiB)
RAID Levels supported: Virtual mode
RAID 1, 5, 6, 10
Enclosures
Expansion Drive Enclosures
0-7 enclosures
LFF/SFF array/enclosure mixing
Supported
Maximum number of drives per array enclosure
24 SFF/12 LFF
Maximum number of drives per drive enclosure
24 SFF/12 LFF
Drive enclosure interface type
6Gb SAS
Product Details Figure 1 shows the rear ports of HPE MSA 2052 Storage.
Note:
①
AC Power supplies
④
Management Ethernet port
②
Host connection ports
8 and/or 16Gb FC,
1 GBE and/or 10GbeE iSCS,
I or 6GB and/or 12Gb SAS
⑤
Expansion port
③
CLI port (mini-USB)
Configuration Information Step 1 - MSA 2052 - Base Configurations
HPE MSA 2052 SAN Dual Controller LFF Storage
Q1J02A
HPE MSA 2052 SAN Dual Controller SFF Storage
Q1J03A
HPE MSA 2052 SAS Dual Controller LFF Storage
Q1J30A
HPE MSA 2052 SAS Dual Controller SFF Storage
Q1J31A
Step 2 – Choose Your SFP+ Module
SFP+ Modules
HPE MSA 8Gb Short Wave Fibre Channel SFP+ 4-pack Transceiver
(Includes four x 8Gb SW FC SFPs)
C8R23B
HPE MSA 16Gb Short Wave Fibre Channel SFP+ 4-pack Transceiver
(Includes four x 16Gb SW FC SFPs)
C8R24B
HPE MSA 10Gb Short Range iSCSI SFP+ 4-pack Transceiver
(Includes four x 10Gb SW iSCSI SFPs)
C8R25B
HPE MSA 1Gb RJ-45 iSCSI SFP+ 4-pack Transceiver
(Includes four x 1Gb RJ-45 iSCSI SFPs)
C8S75B
Step 3 – Select Your Drives
MSA HDDs and SSDs drives are for use with MSA Storage Systems only.
Customers can mix SSD, SAS, and SAS MDL drives in the same array enclosure and disk enclosure
SFF SSDs
12G SFF SAS SSDs (Mixed Use)
HPE MSA 400GB 12G SAS Mixed Use SFF (2.5in) 3yr Warranty Solid State Drive
N9X95A
HPE MSA 800GB 12G SAS Mixed Use SFF (2.5in) 3yr Warranty Solid State Drive
N9X96A
HPE MSA 1.6TB 12G SAS Mixed Use SFF (2.5in) 3yr Warranty Solid State Drive
N9X91A
HPE MSA 3.2TB 12G SAS Mixed Use SFF (2.5in) 3yr Warranty Solid State Drive
N9X92A
SFF HDDs
12G SFF 15K SAS HDDs
HP MSA 300GB 12G SAS 15K SFF (2.5in) Enterprise 3yr Warranty Hard Drive
J9F40A
HP MSA 600GB 12G SAS 15K SFF (2.5in) Enterprise 3yr Warranty Hard Drive
J9F42A
HPE MSA 900GB 12G SAS 15K SFF (2.5in) Enterprise 3yr Warranty Hard Drive
Q1H47A
12G SFF 10K SAS HDDs
HP MSA 300GB 12G SAS 10K SFF(2.5in) Dual Port Enterprise 3yr Warranty Hard Drive
J9F44A
HP MSA 600GB 12G SAS 10K SFF(2.5in) Dual Port Enterprise 3yr Warranty Hard Drive
J9F46A
HP MSA 1.2TB 12G SAS 10K SFF(2.5in) Dual Port Enterprise 3yr Warranty Hard Drive
J9F48A
HP MSA 1.8TB 12G SAS 10K SFF (2.5in) 512e Enterprise 3yr Warranty Hard Drive
J9F49A
NOTE: 512e drives require MSA 1040/2040 firmware version GL200P002 or newer
12G SFF 7.2K SAS MDL HDDs
HP MSA 1TB 12G SAS 7.2K SFF (2.5in) 512e Midline 1yr Warranty Hard Drive
J9F50A
HP MSA 2TB 12G SAS 7.2K SFF (2.5in) 512e Midline 1yr Warranty Hard Drive
J9F51A
NOTE: 512e drives require MSA 1040/2040 firmware version GL200P002 or newer
LFF SSDs
12G LFF SAS SSDs (Mixed Use)
HPE MSA 400GB 12G SAS Mixed Use LFF (3.5in) Converter Carrier 3yr Wty Solid State Drive
P9M79A
HPE MSA 800GB 12G SAS Mixed Use LFF (3.5in) Converter Carrier 3yr Wty Solid State Drive
P9M80A
LFF HDDs
12G LFF 7.2K SAS Midline Drives
HPE MSA 2TB 12G SAS 7.2K LFF (3.5in) 512n Midline 1 yr Warranty Hard Drive
N9X93A
HPE MSA 4TB 12G SAS 7.2K LFF (3.5in) 512e Midline 1yr Warranty Hard Drive
K2Q82A
HPE MSA 6TB 12G SAS 7.2K LFF (3.5in) 512e Midline 1yr Warranty Hard Drive
J9F43A
HPE MSA 8TB 12G SAS 7.2K LFF (3.5in) 512e Midline 1yr Warranty Hard Drive
M0S90A
HPE MSA 10TB 12G SAS 7.2K LFF (3.5in) Midline 512e 1 yr Wty Hard Drive
P9M82A
HPE MSA 12TB 12G SAS 7.2K LFF (3.5in) Midline 512e 1yr Warranty Hard Drive
Q2R42A
SFF SEDs
MSA Small Form Factor (SFF) SAS DP Self-Encrypted Drives
HPE MSA 1.2TB 12G SAS 10K SFF (2.5in) Enterprise Self Encrypted 3yr Wty Hard Drive
P9M81A
LFF SED
MSA Large Form Factor (LFF) SAS DP Self-Encrypted Drives
HPE MSA 4TB 12G SAS 7.2K LFF (3.5in) Enterprise Self Encrypted 3 yr Wty Hard
Q1H48A
Step 4 – Options
Drive Enclosures
HPE MSA 2050 LFF Disk Enclosure
Q1J06A
HPE MSA 2050 SFF Disk Enclosure
Note：
· Each drive enclosure includes two 0.5m MiniSAS to MiniSAS cables
· Add up to 7 additional drive enclosures
· MSA 2050 LFF Disk Enclosure can be connected to either the MSA 2050 SFF or LFF dual controller systems.
· HPE MSA 2050 SFF Disk Enclosure can be connected to either the MSA 2050 SFF or LFF dual controller systems.
Q1J07A
SAS Cable
HP External Mini SAS 1m Cable ALL
407337-B21
HP External Mini SAS 2m Cable
407339-B21
Power Cords
HPE C13 - C14 WW 250V 10Amp 2.0m Jumper Cord
A0K02A
HPE C13 - C14 WW 250V 10Amp Flint Gray 2.0m Jumper Cord
AF573A
HPE C13 - AS3112-3 AU 250V 10Amp 2.5m Power Cord
AF569A
HPE C13 - BS-1363A UK/HK/SG 250V 10Amp 1.83m Power Cord
AF570A
HPE C13 - C14 WW 250V 10A Gray 0.7m Jumper Cord
A0K03A
HPE C13 - C14 WW 250V 10A Gray 1.37m Jumper Cord
A0K04A
HPE C13 - CEE-VII EU 250V 10Amp 1.83m Power Cord
AF568A
HPE C13 - CEI-23-50 IT/CL 250V 10Amp 1.83m Power Cord
AF571A
HPE C13 - CNS-690 TW 110V 13Amp 1.83m Power Cord
AF561A
HPE C13 - DK-2.5A DK 250V 10Amp 1.83m Power Cord
AF566A
HPE C13 - GB-1002 CN 250V 10Amp 1.83m Power Cord
AF557A
HPE C13 - IRAM -2073 AR 250V 10A 2.5m Power Cord
AF558A
HPE C13 - IS-1293 IN 240V 6Amp LV 2.0m Power Cord
AF562A
HPE C13 - JIS C8303 JP 100V 12Amp 2.0m Power Cord
AF572A
HPE C13 - KSC- 8305 KR 250V 10Amp 1.83m Power Cord
AF560A
HPE C13 - NBR-14136 BR 250V 10Amp 1.83m Power Cord
AF591A
HPE C13 - Nema 5-15P US/CA 110V 10Amp 1.83m Power Cord
AF556A
HPE C13 - SABS-164 ZA 250V 10Amp 2.5m Power Cord
AF567A
HPE C13 - SEV 1011 CH 250V 10Amp 1.83m Power Cord
AF565A
HPE C13 - SI-32 IL 250V 10Amp 1.83m Power Cord
AF564A
HPE C13-NEMA 6-15P 10A/250V 3.6m Black Power Cord
A0N33A
HPE OEM C13 - C14 WW 250V 10A Gray 3m Jumper Cord
A0K06A
NOTE:
· Two PDU cables: one 142263-008 (Black) and one 1422633-013 (Grey), ship standard with all AC-powered enclosures.
For more options, please read the datasheet.
