E7W04A Specification |
| Bay Provided |
| Form Factor |
2.5 SFF |
| Total Qty |
24 |
| Free Qty |
24 |
| Dimensions & Weight |
| Width |
19 in |
| Depth |
19.5 in |
| Height |
3.5 in |
| Weight |
29.1 lbs |
| Environmental Parameters |
| Min Operating Temperature |
41 °F |
| Max Operating Temperature |
104 °F |
| Humidity Range Operating |
10 - 90% (non-condensing) |
| Expansion Bays |
| Form Factor (metric) |
6.4 cm SFF |
| Type |
Hot-swap |
| Hard Drive |
| Type |
No HDD |
| Interface Provided |
| Qty |
4 |
| Interface (Storage) |
Ethernet 1000Base-T |
| Purpose Location |
Management |
| Connector Type |
RJ-45 |
| Optical Storage |
| Type |
None |
| Power Device |
| Frequency Required |
50/60 Hz |
| Installed Qty |
2 |
| Max Supported Qty |
2 |
| Power Consumption Operational |
337 Watt |
| Nominal Voltage |
AC 120/230 V |
| Power Redundancy |
Yes |
| Power Redundancy Scheme |
1+1 |
| Hot-Plug |
Hot-plug |
| Type |
Internal power supply |
| Service |
| Support Details Type |
Limited warranty |
| Support Details Service Included |
Parts |
| Support Details Full Contract Period |
3 years |
| Service & Support |
| Type |
3 years warranty |
| Storage |
| Type |
Hard drive array |
| Max Supported Capacity |
28.8 TB |
| Rack-mountable |
Rack-mountable |
| HDD Array External Interface |
iSCSI (10 GbE) |
| Maximum LUNs |
512 |
| HDD Array External Interface Class |
iSCSI |
| Storage Controller |
| Type |
RAID |
| RAID Level |
RAID 0, RAID 1, RAID 10, RAID 3, RAID 5, RAID 50, RAID 6 |
| Data Transfer Rate |
600 MBps |
| Interface Type |
Serial Attached SCSI 2 |
| Buffer Size |
4 GB |
| Installed Qty |
2 |
| Storage Controller (2nd) |
| Type |
None |
| Header |
| Compatibility |
PC |
| Manufacturer |
Hewlett-Packard |
| Packaged Quantity |
1 |
| Product Line |
HPE Modular Smart Array |
| Model |
1040 Dual Controller SFF Storage |
| Brand |
HPE |
| Miscellaneous |
| Compliant Standards |
CCC, China RoHS, CISPR 22 Class A, CISPR 24, CNS 13438, CSA C22.2 No. 60950-1-03, EN 60950-1, EN 61000-3-2, EN 61000-3-3, EN55022 Class A, EN55024 Class A, FCC Class A certified, FCC Part 15, GS, ICES-003 Class A, IEC 60950-1, KN22 Class A, KN24, RoHS 6/6, UL 60950-1, VCCI Class A, WEEE |
| Features |
Firmware upgradable |
| Height (Rack Units) |
2 |
| System Requirements |
| Min Operating System |
Microsoft Windows Server 2008 SP2, Microsoft Windows Server 2012, Red Hat Linux, SUSE Linux Enterprise Server |
Entry consolidation and virtualization initiatives are now well in your budgetary reach. The new HP MSA 1040 Storage offers many of the MSA 2040 features but at lower entry price points.
ProLiant and BladeSystems administrators as well as IT generalists will find storage management tasks simple and intuitive with MSA. The MSA 1040 arrays leverage a new 4th-generation controller architecture with a new processor, 2-host ports and 4GB cache per controller. Take advantage of the latest hard drives advances by choosing the form factor and technology which best meet your application and budget requirements.
Unlike many competing arrays, the MSA 1040 ships standard with intuitive management tools and powerful data services such as Snapshots and Volume Copy for increased data protection.
Quick Specs
Table 1 shows the Quick Specs.
Product Code |
E7W04A |
Description |
MSA 1040 2 Port 10G ISCSI DC SFF Storage |
Product Model |
1040 |
Product Type |
SAN Storage System |
Controller Type |
6Gb/s SAS |
Number of Total Expansion Bays |
24 |
Number of 2.5" Bays |
24 |
Ethernet Technology |
10 Gigabit Ethernet |
Number of Hard Drives Supported |
24 |
Total Hard Drive Capacity Supported |
28.80 TB |
Protocols |
iSCSI |
Height |
11" |
Width |
29" |
Depth |
26" |
Form Factor |
Rack-mountable |
Rack Height |
2U |
Manufacturer |
HPE |
