Capacity Single Enclosure and Maximum Additional Drive Enclosures
LFF: 120 TB (single LFF array-head -using 12 x 10TB LFF SAS MDL drives) 480 TB (by adding 3 LFF Disk Enclosures behind LFF Array & using 10 TB LFF SAS MDL drives)
SFF: 43.2 TB (single SFF array-head - using 24 x 1.8TB SFF SAS drives) 178.2 TB (by adding 3 SFF Disk Enclosures behind SFF Array & using 1.8TB SFF SAS drives)
NOTE: 1) maximum available storage capacity depends on the RAID level being implemented
Pool Capacity
GL200: 169 TB (154 TiB)
GL210: 219 TB (200 TiB)
GL220: 329 TB (300 TiB)
GL220 with Large Pool Support: 562 TB (512 TiB)
NOTE: 1) The above pool capacities by firmware release apply to virtual storage only 2) The above capacities are usable capacity/pool. Each MSA system can support two pools. Therefore each MSA storage system can have double the usable capacity listed above
Cache
6 GB per controller
NOTE: 6GB cache includes Data (Read/Write) cache = 4GB and Metadata and System OS cache = 2GB
Total LUNs (LUN size are dependent of the storage architecture: Linear vs. Virtualized)
size: 140TB (128TiB) Thin Provisioning allows you to create the LUNs independent of the physical storage
Host Interconnect
2 x 8Gb Fibre Channel ports per controller
2 x 1GbE RJ-45 ports per controller
2 x 10GbE ports per controller
2x 12Gb SAS ports per controller
Maximum Drives w/ 3 expansion
48 LFF/99 SFF
Maximum Host Supported
64 in v2 UI
512 in v3 UI
Standard Software
Snapshots (64)
Optional Software
Remote Snap (linear storage only) Max Snapshot (512)
E7W01A is an HPE MSA 1040 2 Port 1G Iscsi DC LFF Storage, including LFF Array Chassis + two MSA 1040 1GbE 2-port controllers, SFPs installed, drives not included. HPE MSA 1040 Storage offers many of the MSA 2040 features but at lower entry price points. ProLiant and BladeSystems administrators as well as IT generalists will find storage management tasks simple and intuitive with MSA. The MSA 1040 arrays leverage a new fourth-generation controller architecture with a new processor, 2-host ports and 4 GB data (read/write) cache and 2 GB of system memory per controller. Take advantage of the latest hard drive and solid state drive advances by selecting the HDD form factor and technology which best meet your application and budget requirements. Unlike many competing arrays, the MSA 1040 ships standard with intuitive management tools and powerful data services such as snapshots for increased data protection.
Quick Spec
Table 1 shows the quick spec.
Model
E7W01A
Capacity Single Enclosure and Maximum Additional Drive Enclosures
120 TB (single LFF array-head -using 12 x 10TB LFF SAS MDL drives) 480 TB (by adding 3 LFF Disk Enclosures behind LFF Array & using 10 TB LFF SAS MDL drives)
Cache
6 GB per controller
Host Interface
MSA 1040 2-port 1GbE iSCSI Controller
Product Details
Figure 1 shows the MSA 1040 Array LFF or supported 12-drive expansion enclosure.
Note:
①
Left ear
⑤
Disk drive Fault/UID LED
②
Disk drive Slots
⑥
Disk drive Online/Activity LED
③
Right ear
⑦
Enclosure ID LED
④
Unit Identification (UID) LED
Heartbeat LED
Fault ID LED
Figure 2 shows the rear panel layout of the MSA 1040 controller enclosure.
